Audio:
-
CPU: Qualcomm Snapdragon 6125 Octa-Core
-
DAC: AKM AK4191EQ x2 & AK4499EX x4
-
Decoding: Supports up to 32bit/768kHz playback
-
Output: Unbalanced (3.5mm), Balanced (4.4mm)
-
Output Level: Unbalanced 3.3Vrms │ Balanced 6.3Vrms (No Load)
-
Sample Rate: PCM: 8kHz ~ 768kHz (8/16/24/32bits per sample), DSD: DSD64(1bit 2.8MHz), Stereo / DSD128(1bit 5.6MHz), Stereo / DSD256(1bit 11.2MHz), Stereo
-
SNR: 126dB @ 1kHz (Unbalanced) │ 130dB @ 1kHz (Balanced)
-
THD+N: 0.0005% @ 1kHz (Unbalanced) │ 0.0003% @ 1kHz (Balanced)
-
Crosstalk: -140dB @ 1kHz (Unbalanced) │ -144dB @ 1kHz (Balanced)
-
Frequency Response: ±0.020dB (20Hz~20kHz) Unbalanced │ ±0.025dB (20Hz~20kHz) Balanced, ±0.032dB (20Hz~70kHz) Unbalanced │ ±0.025dB (20Hz~70kHz) Balanced
-
Clock Source: 25pS (Typ) │ Reference Clock Jitter: 200 Femto Seconds
-
Bluetooth: V5.0 (A2DP, AVRCP, Qualcomm® aptX™ HD, LDAC, LHDC)
Other:
-
Storage: 256GB Internal Memory, MicroSD card slot (supports up to 1.5TB)
-
Battery: 4,200mAh 3.8V Li-Polymer
-
Charge Time: Approximately 3.5 hours (QC3.0 Charging)
%20%E2%80%94%20Scaled%20(30.png){kind=tracking}
Detailed Specifications:
-
Display: 6-inch Full HD (1080x2160) touchscreen.
-
DAC: Dual AKM AK4191EQ and quad AKM AK4498EX DACs.
-
Audio Support: Native playback of PCM up to 32-bit/768kHz and DSD512.
-
Internal Storage: 256GB, expandable via microSD card (up to 2TB).
-
Connectivity:
-
Bluetooth 5.3 with aptX HD, LDAC, and LHDC support.
-
-
Dual-band Wi-Fi (2.4/5GHz).
-
USB-C for charging and PC/MAC connection.
-
3.5mm unbalanced and optical outputs, 4.4mm balanced output.
-
DLNA, AirPlay, and Roon Ready certification.
​
-
BT Sink mode for using the PD10 as a Bluetooth DAC.
-
ReplayGain for uniform volume across tracks.
-
AK File Drop for wireless file transfer.
-
Crossfeed mode for a more natural soundstage.
-
Docking cradle with XLR balanced outputs for home audio integration.
