Tech Specs
Audio Input
- Bring your TV audio, recorder player, CD player, or another audiosource into the digital world via either analog (RCA) 16-bit/48kHzor digital (SPDIF) port, up to 24-bit/192 kHz
Audio Output

• Analog RCA Line OUT, Digital optical (SPDIF) OUT, Digital Coaxial

• OUT, up to 192kHz/24-bit

•  SNR (built-in DAC): 121 dB

•  THD+N (built-in DAC) 0.00025%, -113 dB

Audio Codec

• MP3, AAC, ALAC, APE, FLAC, WAV, WMA, OGG, AIFF

• Connectivity and Power

• USB Type-C, requires 5V, 1.5A or higher/ Bundled adapter: 5V, 2A

• Wi-Fi 5, 802.11 b/g/n/ac 2.4 GHz and 5 GHz dual band Bluetooth 5.0 with BLE, supports both A2DP receiver and transmitter, AVRCP, HID, works with the WiiM Voice Remote

• Ethernet, 10M/100 Mbps

• USB Host – connect to USB disk for local music playback.

• 12 V Trigger-2.5 mm port for cable connection to your amp for

• automated power control
